CMM Fixture Kit
Modular fixture kit for CMM repeatability, datum control and first-article sampling across machined part families.
$8.60 – $32MOQ: 5SKU: DFM-CMM-FX
Inspection File
- Metrology fixture configuration reviewed before quote
- Repeatability 0.003 mm capability documented by inspection plan
- Drawing, spec sheet and QC photo pack available
- Export packing and spare-part notes included
- Private-label documentation supported
Specifications
| Process | Metrology fixture |
|---|---|
| Material | Anodized aluminum / steel pins |
| Tolerance / Grade | Repeatability 0.003 mm |
| Documentation | FAI, dimensional report, QC photos |
| MOQ | 5 sets |
| Lead Time | 25-55 days after drawing approval |
| Trade Terms | FOB / CIF / DAP by project |
Product Detail
Modular fixture kit for CMM repeatability, datum control and first-article sampling across machined part families.
Designed for export machinery buyers
DatumForge Machine Tools prepares drawings, tolerance notes, machine acceptance data, inspection photos and packing requirements before production release.
Inspection file
Each order can include a drawing deviation sheet, first-article report, dimensional checklist, material certificate and shipment photo pack for distributor or EPC review.
